Olivine / Dunite
Olivine/ Dunite Flour
The mineral olivine is a magnesium iron silicate with the chemical formula (Mg,Fe)2SiO4. It is a type of nesosilicate or orthosilicate. The primary component of the Earth's upper mantle, it is a common mineral in Earth's subsurface, but weathers quickly on the surface. For this reason, olivine has been proposed as a good candidate for accelerated weathering to sequester carbon dioxide from the Earth's oceans and atmosphere, as part of climate change mitigation. Olivine also has many other historical uses, such as the gemstone peridot (or chrysolite), as well as industrial applications like metalworking processes.
Olivine in cross-polarized light
The ratio of magnesium to iron varies between the two endmembers of the solid solution series: forsterite (Mg-endmember: Mg2SiO4) and fayalite (Fe-endmember: Fe 2SiO4). Compositions of olivine are commonly expressed as molar percentages of forsterite (Fo) and fayalite (Fa) (e.g., Fo70Fa30). Forsterite's melting temperature is unusually high at atmospheric pressure, almost 1,900 °C (3,450 °F), while fayalite's is much lower – about 1,200 °C (2,190 °F). Melting temperature varies smoothly between the two endmembers, as do other properties. Olivine incorporates only minor amounts of elements other than oxygen (O), silicon (Si), magnesium (Mg) and iron (Fe). Manganese (Mn) and nickel (Ni) commonly are the additional elements present in highest concentrations.
Olivine gives its name to the group of minerals with a related structure (the olivine group) – which includes tephroite (Mn2SiO4), monticellite (CaMgSiO4), larnite (Ca2SiO4) and kirschsteinite (CaFeSiO4) (commonly also spelled kirschteinite).
Olivine sand
Olivine sand is an ideal mineral to use for the production of manganese steel castings as it is chemically less reactive than silica sand. SiO2 reacts with MnO in the steel to form a MnSiO3 slag resulting in serious burn on defects. A further advantage is that olivine sand has a low thermal expansion rate compared to silica sand and its high thermal shock resistance furthermore reduces sand expansion problems.
